RCH530D Full Hydraulic Pile Driver with Cummins Diesel Engine 97kw Engine
Product Description
Crawler mounted pile drivers are widely used for highway guardrail post installation, garden fence installation and small foundation construction.The machine has mainly 3 functions: ramming, DTH impact drilling, as well as pulling out the posts . With these functions, the machine can meet the requirement for most projects.
Main Components:
(1) Hydraulic pump
(2) Hydraulic motor
(3) Multi-directional control valves and centralized hydraulic control rods
(4) Changchai brand diesel engine
(5) Hydraulic hammer and hammer adapter
(6) Pile extractor
Product Specifications
| Model | RCH530D |
| Transportation size (L*W*H) | 6500mm*2200mm*2700mm |
| Working Size (L*W*H) | 3500mm*2200mm*7500mm |
| Crawler Size | 2550mm*1700mm*530mm |
| Vehicle Weight | 4500-5200KG |
| Diesel Engine Rated Power | 70KW |
| Flow Rate of Hydraulic System | 113.4L/Min |
| Hydraulic Pressure(Max) | 20Mpa |
| Mast Stroke | 200-5500 |
| Hydraulic Hammer | YC360 (85MM borehole rod) |
| Impact | 1300J |
| Piling efficiency | 3200mm/Min |
| Drilling Depth(Max) | 3500mm |
| Borehole Diameter | 50-300mm |
| Climbing Ability(Max) | 30° |
| Speed | 3.8KM/H |
| Left/Right Sliding Stroke(Max) | 500mm |
| Max Inclination Angle of Sliding Guide Frame | Left 30°/Right 8° |
| Front / Rear Adjusting angle of frame | Front 75°/ Rear 15° |
| Min Ground Clearance | 230mm |
| Capacity of Hydraulic Oil Tank | 80L |
| Capacity of Diesel Tank | 80L |
Product Features
1. Both wheeled and crawler type moving mode for choice.
2. Mainly Diesel engine driven, and other optional driving unit could meet different customers ’ needs for different construction demands;
3. Easily operation.
4. High-efficiency
5. Energy-saving
6. this pile Machine is equipped with angle gauge, which helps the operator adjust the direction in time and ensure vertical drilling.
7. Wide view cabin, which facilitate the operator to observe the working environment
8. Intelligent design makes different hammer adapters/bits/head is suitable for different shape posts for your choice, like C-shape, H-shape, U-shape, Sigma shape etc.
Product Image
